Features
- Low-profile, high-output
- Spot, Flood, Driving, and Diffused beam options
- Surface or flush mount with flexible bracket options
- Upgrade your reverse game with SR-Q Diffused
Specifications
Size: 2"X5"
Light Shape: POD
Mount Type: SURFACE MOUNT
Beam Category: FLOOD
Voltage Range: 9V - 36V
Current Draw at 14V (a): 2.29
Raw Lumens: 3168
Watts: 32
Lux @10m: 69.24
Beam Distance @ 1 LUX: 83.2
Beam Distance @ .25 LUX: 166.4
Peak Beam Intensity(cd): 6924
Horizontal Beam Angle: 50.8
Vertical Beam Angle: 42.1
Dimensions
Product Height: 1.8 in
Product Width: 5 in
Product Depth: 2.23 in
Product Weight: 0.738 lbs
What's In The Box
Single Light
Mounting Hardware
Stainless Steel U-Shape Bracket
Harness & Switch (no Relay)
Deutsch Connector
Black Light Cover
DIFFERENT TYPES OF BEAM PATTERNS
Flood Beam
Moderate 20° beam for trail and overland use. Offers long-distance illumination with a wider spread than spot beams.
