Features
- Halo Backlighting Availble in 3 Colors: Red, White or Blue
- Ultra-Wide 70 Degree Beam Pattern
- Hidden Mounting Hardware
- 3 Functions: High Power, Low Power, Halo Backlight
- Soft Start When in High or Low Power Modes
- Available in White or Black Housing
- 18 Inch Cable With Waterproof Ingress Connector & Wire Harness Adapter Included
- Alodine Treated to Inhibit Corrosion
- 9-36 VDC
- Durable UV Powder Coat
- UV Protected Polycarbonate Lens
- Integrated Thermal Management
- Patented Optics
- Pressure Equalizing Vent
- IP68 Rated for Dust/Water Ingress
- Over / Under Voltage Protection
- Limited Lifetime Warranty
- Off Road Use Only
Specifications
Size: 20"
Light Shape: BAR
Mount Type: SURFACE MOUNT
Beam Category: WIDE DRIVE
Voltage Range: 9V - 36V
Current Draw at 14V (a): 9
Raw Lumens: 13068
Watts: 126
Lux @10m: 258
Beam Distance @ 1 LUX: 161
Beam Distance @ .25 LUX: 321
Peak Beam Intensity(cd): 25832
Horizontal Beam Angle: 74
Vertical Beam Angle: 20
Dimensions
Product Height: 2.01 in
Product Width: 19.66 in
Product Depth: 3.27 in
What's In The Box
Single Light Bar
Mounting Hardware
Stainless Steel L-Shape Brackets
Harnes & Switch w/Relay
DIFFERENT TYPES OF BEAM PATTERNS
Rear Diffused
Beam Pattern
Wide-angle beam (~120°+) with soft, glare-free light. Ideal for reverse lights, work zones, and scene lighting.
