Features
- Ultra-wide 70 Degree Beam Pattern
- Hidden mounting hardware
- 3 Functions: High power, Low power, Halo backlight
- Soft start when in high or low power modes
- 18 Inch cable with waterproof ingress connector & wire harness adapter included
- Alodine treated to inhibit corrosion
Specifications
Size: 20"
Light Shape: BAR
Mount Type: SURFACE MOUNT
Beam Category: WIDE DRIVE
Voltage Range: 9V - 36V
Current Draw at 14V (a): 9
Raw Lumens: 13068
Watts: 126
Lux @10m: 258
Beam Distance @ 1 LUX: 161
Beam Distance @ .25 LUX: 321
Peak Beam Intensity(cd): 25832
Horizontal Beam Angle: 74
Vertical Beam Angle: 20
Dimensions
Product Height: 2.01 in
Product Width: 19.66 in
Product Depth: 3.27 in
Product Weight: 5.8 lbs
What's In The Box
Single Light Bar
Mounting Hardware
Stainless Steel L-Shape Brackets
Harnes & Switch w/Relay
DIFFERENT TYPES OF BEAM PATTERNS
Rear Diffused Beam
Wide-angle beam (~120°+) with soft, glare-free light. Ideal for reverse lights, work zones, and scene lighting.
LEARN MORE about Beam Patterns
