- Double –row power for maximum output
- Spot, Flood, Driving, Hyperspot, Diffused, and combo beam options
- Built for off-road, but ready for anything— powersports, overlanding, even first responders
- One of the brightest, toughest bars on the market
Size: 20"
Light Shape: BAR
Mount Type: SURFACE MOUNT
Beam Category: SPOT HYPERSPOT COMBO
Voltage Range: 9V - 36V
Current Draw at 14V (a): 11.14
Raw Lumens: 20344
Watts: 156
Lux @10m: 5690
Beam Distance @ 1 LUX: 754
Beam Distance @ .25 LUX: 1509
Peak Beam Intensity(cd): 569046
Horizontal Beam Angle: 14
Vertical Beam Angle: 11
Product Height: 3.25 in
Product Width: 21.5 in
Product Depth: 3.75 in
Product Weight: 6.1 lbs
What's In The Box
Single Light Bar
Black Powder Coated L-Shape Brackets
Harness & Switch w/Relay
Mounting Hardware
DIFFERENT TYPES OF BEAM PATTERNS
Hyperspot Beam
Ultra-focused beam under 5° for extreme range. Built for racing and pre-running, it delivers maximum distance with minimal spread.
LEARN MORE about Beam Patterns
Spot Beam
Designed for long distance visibility with a narrow 10° beam. Perfect for high-speed driving in open terrain, it helps you spot obstacles far ahead.
LEARN MORE about Beam Patterns
